Specifications
General Description
CD Transport
Design Philosophy and Core Technology
Compatible with CD/CD-R/CD-RW
Support playing USB storage devices (MP3/WMA/AAC/WAV)
Display indication
Adjustable screen brightness
Activate the device automatically via 12V trigger
Auto standby function can be turned on or off
USB Storage Device Audio Format
Support MP3, WMA, AAC, WAV format playback
USB Storage Device File System
Support FAT12, FAT16 and FAT32 format
Digital Output Amplitude
500 +/-50mVpp
Output Impedance
75Ω
Frequency Response
-0.01dB (20Hz-20kHz, ref.1kHz)
Total Harmonic Distortion (THD)
< 0.002%
Sampling Rate
44.1kHz
Digital Output Interface
1 x Coaxial, 1 x Optical
Standby Power Consumption
< 0.5W
Power Requirements (according to region)
220-240V - 50/60Hz
Product Size (mm) (W x D x H)
444 x 322 x 78
Carton Size (mm) (W x D x H)
514 x 470 x 158
Net Weight
5.5kg
Gross Weight
7.4kg
